Youthpower Solar Energy Storage System LiFePO4 48V 51.2V 300ah 400ah 15kwh 20kwh Residential Home Solar Battery
Description
Basic Info
| Model NO. | YP51400 20KWH |
| Installation | Packaged |
| Rechargeable | Chargeable |
| Transport Package | 1PC / Inner Box, 2 Box / Pallet |
| Specification | 51.2V 400AH |
| Trademark | YouthPOWER |
| Origin | China |
| Production Capacity | 500 Units / Day |
Product Description
51.2V 400AH 20KWH Lifepo4 Battery
YOUTHPOWER YP51400 20KWH is a fully - integrated home storage system with Lifepo4 batteries, applied for easily retrofitted to an existing solar PV installation. The system stores energy generated during the day and discharge at night when household electricity demand peaks. We expect the battery pack about 20 years life and more than 6000 cycles.
Enjoy easy installation and cost with Youth Power Home SOLAR WALL BATTERY, We are always ready to supply the first-class products and meet the various needs of the customers.
Part Number: YP 51400-20KW
Brand: YouthPOWER
Voltage: 51.2V
Capacity: 400AH
Power: 20KWH
| Product Specification | |
| Model No | YP51400 20KWH |
| Nominal Parameters | |
| Voltage | 51.2V |
| Material | Lifepo4 |
| Capacity | 400Ah |
| Energy | 20.48KwH |
| Dimensions (L x W x H) | 920 x 220 x 730 mm |
| Weight | 198KG |
| Basic Parameters | |
| Life time(25° C) | Expected Life time |
| Life cycles(80% DOD, 25° C) | 6000 Cycles |
| Storage time / temperature | 5 months @ 25° C; 3 months @ 35° C; 1 month @ 45° C |
| Operation temperature | -20° C to 60° C @60+/-25% Relative Humidity |
| Storage temperature | 0° C to 45° C @60+/-25% Relative Humidity |
| Lithium Battery Standard | , IEC62619, UN38.3, MSDS, CE-EMC |
| Enclosure protection rating | IP21 |
| Electrical Parameters | |
| Operation voltage | 51.2 Vdc |
| Max. charging voltage | 58 Vdc |
| Cut-off-Discharge Voltage | 46 Vdc |
| Max, charging and discharging current | 200A |
| Compatibility | Compatible with all standard off grid inverters and charge controllers.Battery to inverter output sizing keep 2:1 ratio. |
| Warranty Period | warranty 5-10 years |
| Remarks | Youth Power battery BMS must be wired in parallel only. Wiring in series will void the warranty. |
Selective lifepo4 cells:
IEC A grade Lifepo4 cells applied
Using lithium iron phosphate cell, low internal resistance, high rate, high safety, long life. High consistency of internal resistance, voltage and capacity of single cell.
Smart BMS System:
Smart BMS with function of single battery voltage detection, battery temperature NTC detection etc. Perfect BMS protection function and control system, over current, over voltage, insulation and other multiple protection design
Supports communication protocol such as CAN2.0 and RS485, which can be used in various scenarios.
